Product Summary
The HD64F3664HV is a single-chip microcomputer made up of the high-speed H8/300H CPU employing Renesas Technology original architecture as their cores, and the peripheral functions required to configure a system. The HD64F3664HV CPU has an instruction set that is compatible with the H8/300 CPU.
Parametrics
HD64F3664HV absolute maximum ratings: (1)Power supply voltage: –0.3 to +7.0 V; (2)Analog power supply voltage: –0.3 to +7.0 V; (3)Input voltage: Ports other than Port B and X1: –0.3 to VCC +0.3 V, Port B: –0.3 to AVCC +0.3 V, X1: –0.3 to 4.3 V; (4)Operating temperature: –20 to +75 ℃; (5)Storage temperature: –55 to +125 ℃.
Features
HD64F3664HV features: (1)High-speed H8/300H central processing unit with an internal 16-bit architecture: Upward-compatible with H8/300 CPU on an object level, Sixteen 16-bit general registers, 62 basic instructions; (2)Various peripheral functions: Timer A (can be used as a time base for a clock), Timer V (8-bit timer), Timer W (16-bit timer), Watchdog timer, SCI3 (Asynchronous or clocked synchronous serial communication interface), I2C Bus Interface (conforms to the I2C bus interface format that is advocated by Philips Electronics), 10-bit A/D converter; (3)On-chip memory.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
HD64F3664HV |
IC H8 MCU FLASH 32K 64QFP |
Data Sheet |
|
|
||||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||
HD6412240TE13 |
IC H8S MPU ROMLESS 100TQFP |
Data Sheet |
Negotiable |
|
||||||||
HD6412322RVF25 |
IC H8S MCU ROMLESS 128-QFP |
Data Sheet |
Negotiable |
|
||||||||
HD6412322RVFBL25 |
IC H8S MCU ROMLESS 128-QFP |
Data Sheet |
Negotiable |
|
||||||||
HD6412332VFCBL25 |
Renesas Technology America |
IC H8S MCU ROMLESS 144-QFP |
Data Sheet |
Negotiable |
|
|||||||
HD6412350F20 |
IC H8S MPU ROMLESS 5V 128QFP |
Data Sheet |
Negotiable |
|
||||||||
HD6412350F20V |
IC H8S MPU ROMLESS 5V 128QFP |
Data Sheet |
Negotiable |
|
