Product Summary

The TMP68303F-16 is a high-speed, high-function 16-bit microprocessor developed for applications on control devices. The TMP68303F-16 uses the 68HC000, the CMOS version of the 6800, as its core processor. It also includes peripheral circuits such as a serial interface, parallel interface, timer, interrupt controller, DMA controller, DRAM controller, stepping motor controller, and address decoder.

Parametrics

TMP68303F-16 absolute maximum ratings: (1)power supply voltage, VCC: -0.3 to 6.5V; (2)input voltage, VIN: -0.3 to 6.5V; (3)operating temperature, Ta: 0 to 70℃; (4)storage temperature, Tstg: -55 to 150℃.

Features

TMP68303F-16 features: (1)core processor 68HC000; (2)minimum instruction excution time; (3)1732-bit registers; (4)16M-byte direct addressing; (5)56 powerful basic instructions; (6)14 addressing modes.

Diagrams

TMP68303F-16 block diagram
