Product Summary

The IDT23S05E-1DCGI is a high-speed phase-lock loop (PLL) clock buffer, designed to address high-speed clock distribution applications. The zero delay is achieved by aligning the phase between the incoming clock and the output clock, operable within the range of 10 to 200MHz. The applications of the IDT23S05E-1DCGI are SDRAM, Telecom, Datacom, PC Motherboards/Workstations, Critical Path Delay Designs.

Parametrics

IDT23S05E-1DCGI absolute maximum ratings: (1)Supply Voltage Range: –0.5 to +4.6V; (2)Input Voltage Range (REF):–0.5 to +5.5V; (3)Input Voltage Range: –0.5 to VDD+0.5V; (4)Input Clamp Current:–50mA; (5)Continuous Output Current: ±50mA; (6)Continuous Current: ±100mA; (7)Maximum Power Dissipation: 0.7W; (8)Storage Temperature Range: –65 to +150°C; (9)Operating Commercial Temperature: 0 to +70°C; (10)Operating Industrial Temperature: -40 to +85 °C.

Features

IDT23S05E-1DCGI features: (1)Phase-Lock Loop Clock Distribution; (2)10MHz to 200MHz operating frequency; (3)Distributes one clock input to one bank of five outputs; (4)Zero Input-Output Delay; (5)Output Skew < 250ps; (6)Low jitter <200 ps cycle-to-cycle; (7)IDT23S05E-1 for Standard Drive; (8)IDT23S05E-1H for High Drive; (9)No external RC network required; (10)Operates at 3.3V VDD; (11)Power down mode; (12)Spread spectrum compatible; (13)Available in SOIC package.

Diagrams

IDT23S05E-1DCGI block diagram
