HD64F2318VTE25V

single-chip microcomputer, QFP, –0.3 to +4.3 V, Renesas, HD64F2318VTE25V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.00~8.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $8.00~8.25

PartNumber:: HD64F2318VTE25V

Brand:: Renesas Technology Corp - Renesas | Pack: QFP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Steven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-07

From Other Seller

Part Number:HD64F2318VTE25V
US $8.00 - 8.25
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HD64F2318VTE25V is a single-chip microcomputer made up of the H8S/2000 CPU with an internal 32-bit architecture as its core, and the peripheral functions required to configure a system. This LSI HD64F2318VTE25V is equipped with ROM, RAM, a bus controller, data transfer controller (DTC), a 16-bit timer pulse unit (TPU), a watchdog timer (WDT), a serial communication interface (SCI), a D/A converter, an A/D converter, and I/O ports as on-chip supporting modules. This LSI HD64F2318VTE25V is suitable for use as an embedded processor for high-level control systems.

Parametrics

HD64F2318VTE25V absolute maximum ratings: (1)Power supply voltage, VCC: –0.3 to +4.3 V; (2)Input voltage (except port 4), Vin: –0.3 to VCC +0.3 V; (3)Input voltage (port 4), Vin: –0.3 to AVCC +0.3 V; (4)Reference power supply voltage, Vref: –0.3 to AVCC +0.3 V; (5)Analog power supply voltage, AVCC: –0.3 to +4.3 V; (6)Analog input voltage, VAN: –0.3 to AVCC +0.3 V; (7)Operating temperature Topr Regular specifications: –20 to +75℃; Wide-range specifications: –40 to +85℃; (8)Storage temperature Tstg: –55 to +125℃.

Features

HD64F2318VTE25V features: (1)Address space divided into 8 areas, with bus specifications settable independently for each area; (2)Chip select output possible for each area; (3)Choice of 8-bit or 16-bit access space for each area; (4)2-state or 3-state access space can be designated for each area; (5)Number of program wait states can be set for each area; (6)Burst ROM directly connectable; (7)External bus release function.
