Product Summary

The LM75BIMX-3 is a temperature sensor, Delta-Sigma analog-to-digital converter, and digital over-temperature detector with I2C interface. The 3.0V to 5.5V supply voltage range, low supply current and I2C interface make the LM75BIMX-3 ideal for a wide range of applications. The applications of the LM75BIMX-3 are System Thermal Management, Personal Computers, Office Electronics, Electronic Test Equipment.

Parametrics

LM75BIMX-3 absolute maximum ratings: (1)Supply Voltage:-0.3V to 6.5V; (2)Voltage at any Pin:-0.3V to +VS + 0.3V; (3)Input Current at any Pin:5 mA; (4)Package Input Current:20 mA; (5)O.S. Output Sink Current:10 mA; (6)O.S. Output Voltage:6.5V; (7)Storage Temperature:-65℃ to +150℃; (8)ESD Susceptibility:Human Body Model:2500V, Machine Model:250V.

Features

LM75BIMX-3 features: (1)SOP-8 and Mini SOP-8 (MSOP) packages save space; (2)I2C Bus interface; (3)Separate open-drain output pin operates as interrupt or comparator/thermostat output; (4)Register readback capability; (5)Power up defaults permit stand-alone operation as thermostat; (6)Shutdown mode to minimize power consumption; (7)Up to 8 LM75s can be connected to a single bus; (8)UL Recognized Component.

Diagrams

LM75BIMX-3 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM75BIMX-3
LM75BIMX-3

National Semiconductor (TI)

Board Mount Temperature Sensors

Data Sheet

0-2500: $0.48
2500-5000: $0.46
5000-10000: $0.45
LM75BIMX-3/NOPB
LM75BIMX-3/NOPB

National Semiconductor (TI)

Board Mount Temperature Sensors DIGITAL TEMP SENSOR

Data Sheet

0-1: $1.10
1-25: $0.89
25-100: $0.80
100-250: $0.71
LM75BIMX-3+
LM75BIMX-3+

Maxim Integrated Products

Board Mount Temperature Sensors 2-Wire Digital Temp Snsr & Thrml Wtchdog

Data Sheet

0-2080: $0.57
